3. Cabling
3-40
TI 33J01J10-01EN
l Spring Clamp Terminal
CAUTION
• The CENTUM VP uses a spring clamp terminal for signal connection of N-IO.
manufacturer.
• Use a clamp tool which suits the cable thickness.
of the main unit before connecting or disconnecting a cable.
n Signal Cable Termination
l Pressure Clamp Terminal (for FIO Module Pressure Clamp Terminal Block)
• Terminal processing
when it is used.
Table Without a sleeve
Cable thickness (mm
2
) Length of coating stripped (mm) Remarks
11 —
Table With a sleeve
Cable
thickness
(mm
2
)
When using a sleeve with an isolation cover When using a sleeve without an isolation cover
Length of
coating
stripped
(mm)
Sleeve size
Model No. of
Weidmuller
Length of
coating
stripped
(mm)
Sleeve size
Model No. of
Weidmuller
Total
length
(mm)
Contact
section length
(mm)
Total length
(mm)
0.5 11 16 10 11 10
0.75 11 16 10 11 10
1 11 16 10 11 10
1.25 to 1.5 11 16 10 11 10
1.25 to 1.5 13 18 12 13 12
Oct. 5, 2018-00
To Next Page
