3. Cabling
3-59
TI 33Q01J10-01E
3.6.4 Implementation and Cable Connection of Fieldbus
Communication Module ALF111
This section describes the implementation and cable connection of the Foundation Fieldbus
Communication Module ALF111.
Foundation fieldbus H1 (Low Speed Voltage Mode) is called Foundation fieldbus, Fieldbus, H1
Fieldbus, FF, or FF-H1 in this manual.
Example of Implementation of Fieldbus Communication Module
ALF111
To connect Fieldbus using the ALF111, the power supply unit for the Fieldbus must be prepared
as shown below.
The example of the implementation and the wiring of the ALF111 is shown below.
For the implementation of the ALF111 and the relevant devices, follow the implementation
conditions for the devices. 1 U (unit) = 44.45 mm.
F030612.ai
+
CH1
CH2
CH3
CH4
–
+
–
+
–
+
–
+
–
+
–
+
–
+
–
+
–
+
–
24 V DC
OUT
READY
TN1
+
–
+
–
24 V DC
OUT
READY
TN1
+
–
+
–
24 V DC
OUT
READY
TN1
+
–
+
–
24 V DC
OUT
READY
TN1
U
L
U
L
4U
5U
1U
4U
3U
PW60

ESB bus
Primary
power distribution unit
FG (When using
isolation bushing)
To MAIN PDB
End Plate (both ends)
MTL5995
(Power supply unit for Fieldbus)
+
ALF111
ALF111+ATF9S
AKB336
(20PIN-20PIN)
AEP9D
AEF9D
To Field device
19-inch rack
FG
(When using
isolation
bushing)
3U(*1)
3U (*1)
3U (*2)
MTLMS010
(spacer)
*1: Reserve a space of 3U for heat radiation.
*2: Reserve a space of 3U for heat radiation and wiring.
Figure Example of ALF111 Implementation
