3. Cabling
3-88
TI 33J01J10-01EN
n A2SAT105 mV/TC/RTD input adaptor
9.
When connnecting a TC input or mV input
When connnectinga an RTD input
When connnecting a potentiometer input
F030721.ai
A
B
C
D
‒
+
A
B
C
D
A
B
C
D
0%
100%
Figure When using the mv/TC/RTD input adaptor
with RJC.
SEE
ALSO
the standards they must conform to, refer to:
n A2SDV105 Digital input adaptor
adaptor. The dry contact input is not supported for A2BN3D-9
it is necessary to change the adaptor to A2SMX801 and set the DI mode by software for the
F030713.ai
+
‒
+
‒
A
B
C
D
A
B
C
D
Connect voltage input Connect no-voltage contact input
: 1 to 16
Figure When Using the digital Input Adaptor
n A2SDV505 Digital output adaptor
adaptor.
F030714.ai
A
B
C
D
‒
+
: Load
: 1 to 16
Figure When Using the digital output adaptor
Oct. 5, 2018-00
