1. System Installation Requirements
1-2
TI 33Q01J10-01E
1.1 Control Room Design
The control room, in which the system control equipment is to be installed, should be
designed in accordance with the following conditions:
General
In designing a control room, ensure adequate floor strength and air conditioning including dust-
and moisture-proofing.
SEE
ALSO
1.1 Control Room Design Air Conditioner
1.2 Control Room Environment Air Purity
Applied Standards (Table JEIDA-63-2000 Classification of
Installation Environment Specifications)
Floor Strength and Space
The floor should have adequate strength, and you should design the layout in accordance with
the weight and size of equipment to be installed.
SEE
ALSO
For the maintenance space required, refer to 2.4, “Servicing Area.”
For the weight and dimensions of standard equipment, refer to “External Dimensions(TI 33Q01J10-02E).
Floor Structure
To prevent damage to cables by operators and maintenance equipment, do not lay cables on the
floor.
Lay cables under the floor as follows:
Provide an “accessiblefloor which also facilitates maintenance work.
Make cable pits under the floor if it is concrete.
Flooding- & Dust-proof Floor
To protect equipment and cables, design a flooding-proof floor.
After the cabling is completed, seal all cable conduits using putty to prevent intrusion of dust,
moisture, rats, and insects into the equipment.
Nov. 20, 2003-00
