1.6 Cabling Requirements
The following requirements must be fulfilled when laying power and signal cables (These
are shielded cables unless specified).
Any signal cable used for high-voltage, high-frequency signals (inductive load ON/ OFF)
must be separated from other signal cables.
Separator
Provide a separator between power and signal cables as illustrated below:
Signal
cables
Power
cables
Separator (steel plate)
100 ohms or less;
separate from CS 3000 system grounding
F010601.ai
Figure Separator Used in Duct/Pit
Distance between Cables
If a separator cannot be used, keep a distance between signal cables and power cables.
The distances between cables due to operating voltages and currents are shown below.
Table Required Distance between Power & Shielded Signal Cables
Operating voltage Operating current Distance
240 V AC max. 10 A max. 150 mm min.
240 V AC max. 10 A min. 600 mm min.
240 V AC min. 10 A max. 600 mm min.
240 V AC min. 10 A min.
Cannot be laid
together.
Power cables
F010602.ai
150 mm
or more
Signal cables
Signal cables Power cables
150 mm
or more
Figure Distance between Cables under Pit/Free-access Floor
