3.7 Connecting Signal Cables with Remote I/O
(RIO)
This section describes the signal connections with Remote I/O (RIO) used on the AFS10S/
AFS10D, AFG10S/AFG10D, AFS20S/AFS20D, AFG20S/AFG20D, or PFCS/PFCD.
3.7.1 I/O Module Nests
I/O Modules Nests are available in the following types:
• AMN11: Nest for Analog I/O Modules
• AMN12: High-Speed Nest for Analog I/O Modules (for AF
10 and AF20)
• AMN21: Nest for Relay I/O Modules
• AMN31: Nest for Terminal-type I/O Modules
• AMN32: Nest for Connector-type I/O Modules
• AMN33: Nest for Communication Modules
• AMN34: Nest for Multipoint Control Analog I/O Modules
• AMN51: Nest for Communication Cards and Ethernet Communication Modules
(for PFC
 only)
• AMN52: Nest for Profibus Communication Module (in PFC
 only)
F030730.ai
Multiplexer Modules or
Digital I/O Modules
(Connector Type)
Profibus
Communication Modules
Communication
Modules
Multipoint Control
Analog I/O Modules
Communication
Cards
Analog I/O Module Multiplexer Modules or
Digital I/O Modules
(Terminal Type)
Nest for Connector-type
I/O Modules
(AMN32)
Relay I/O Module
Nest for Communication
Modules
(AMN33)
Nest for Multipoint Control
Analog I/O Modules
(AMN34)
Nest for Communication Cards
and Ethernet Communication
Modules (AMN51)
Nest for Profibus
Communication Modules
(AMN52)
Nest for Analog I/O
Modules
(AMN11, AMN12)
Nest for Terminal-type I/O
Modules
(AMN31)
Nest for Relay I/O
Modules
(AMN21)
Figure I/O Module Nest Configuration
