3. Cabling
3-86
TI 33J01J10-01EN
Oct. 5, 2018-00
lWhen receiving current pulse signals (2-wire power supply type)



 
 
 


substituted by connecting a shunt resistor unit between terminal-B and C on the external terminal
block.

A2SAP105
SW1
4 kΩ
SW2
FIL
12 V DC/24 V DC
INC
IND
(A2EXR001 is selectable from 220 Ω, 510 Ω, and 1.02 kΩ.)
Transmitter
INA
INB
F030710.ai
A2EXR001
Direct field wiring to base plate
INC
IND
DIN rail
Signal Line
Shunt resistor unit
(A2EXR001)
Terminal block of A2BN3D
Shunt resistor module

A

B
INA
INB
: 1 to 16
F030727.ai
A2SAP105
SW1
4 kΩ
SW2
12 V DC/24 V DC
INC
INA
INB
A2EXR001
(A2EXR001 is selected from 220 Ω, 510 Ω, 1.02 kΩ)
Dedicated cable
＋A2BM4
Input filter
Transmiter
External
terminal block
Field wiring via terminal board
INC
INB
DIN rail
Shunt resistor unit
(A2EXR001)
External terminal block
Shunt resistor module

A

B
INA
: 1 to 16
Signal Line
Figure When receiving current pulse signals (2-wire power supply type)
