<APPENDIX 9. DD MENU>
A9-8
IM 01F06F00-01EN
(9) AR Function Block
Menus
Block Info
| Block Tag
| Tag Description
| Strategy
| Alert Key
Block Mode
| Target
| Actual
| Permitted
| Normal
Dynamic Variables
| Inputs
| | Input
| | | Status
| | | Value
| | Input Low
| | | Status
| | | Value
| | Input 1
| | | Status
| | | Value
| | Input 2
| | | Status
| | | Value
| | Input 3
| | Status
| | Value
| Output
| | Status
| | Value
| Process Value
| | Status
| | Value
| Pre Output
| | Status
| | Value
|
Density Factor
| Status
| Value
| Density Factor Unit
Configuration
| Block Mode
| | Target
| | Actual
| | Permitted
| | Normal
| Input Parameters
| | Range Extension
| | | Range High
| |
| |
| |
| Range Low
| | Bias/Gain
| | | Bias Input 1
| | | Gain Input 1
| | | Bias Input 2
| | | Gain Input 2
| | | Bias Input 3
| | | Gain Input 3
| | Input Options
| | Process Value Scale
| | EU at 100%
| | EU at 0%
| | Units Index
| | Decimal
| Algorithm Parameters
| | Arithmetic Type
| | Compensation High Limit
| | Compensation Low Limit
| Output Parameters
| | Balance Time
| | Bias
| | Gain
| | Output High Limit
| | Output Low Limit
| | Output Range
| | EU at 100%
| | EU at 0%
| | Units Index
| | Decimal
| Density Factor Parameters
|
Density Factor Setup Wizard
| Volumetric Flow Unit
| Temperature Set
| Temperature Unit
| Base Temperature
| Pressure Set
| Pressure Unit
| Base Pressure Abs.
| Density Set
| Density Unit
| Base Density
|
Other Value Set
| Deviation
| First Temperature Coef.
| Second Temperature Coef.
|
Flow Configuration Coef.
|
Maintenance Info
| Configuration Soft Revision
| Configuration Date
| Configuration Who
| Configuration Status
| Configuration Memo 1
| Configuration Memo 2
| Configuration Memo 3
| Configuration Setting Info
|
Diagnostics/Alerts
| Block Error
| Alert Parameters
| Block Alarm
| | Unacknowledged
| | State
| | Time Stamp
| | Subcode
| | Value
| Update Event
| Unacknowledged
| Update State
| Time Stamp
| Static Rev
| Relative Index
Others
| Grant Deny
| Grant
| Deny
Query Device
AR Standard parameters
AR Enhanced parameters
FA0908.ai
Note: Parameter name may differ according to a tool or host.
