YOKOGAWA digitalYEWFLO Series User Manual

<APPENDIX 9. DD MENU>
A9-9
IM 01F06F00-01EN
(10) PID Function Block
Menus
Block Info
| Block Tag
| Tag Description
| Strategy
| Alert Key
Block Mode
| Target
| Actual
| Permitted
| Normal
Dynamic Variables
| Cascade Input
| | Status
| | Value
| Setpoint
| | Status
| | Value
| Input
| | Status
| | Value
| Process Value
| | Status
| | Value
| Output
| | Status
| | Value
| Back Calculation Input
| | Status
| | Value
| Back Calculation Output
| | Status
| | Value
| Remote I/O
| | Remote Cascade Input
| | | Status
| | | Value
| | Remote Out Input
| | | Status
| | | Value
| | Remote Cascade Output
| | | Status
| | | Value
| | Remote Out Output
| | Status
| | Value
| Others
| | Feed Forward Value
| | | Status
| | | Value
| | Tracking Value
| | | Status
| | | Value
| | Tracking Input Discrete
| | Status
| | Value
Configuration
| Block Mode
| | Target
| | Actual
| | Permitted
| | Normal
| Scaling/Filter/Limits
| | Process Value Scale
| | | EU at 100%
| | | EU at 0%
| | | Units Index
| | | Decimal
| | Output Scale
| | | EU at 100%
| | | EU at 0%
| | | Units Index
| | | Decimal
| | Setpoint Rate Down
| | Setpoint Rate Up
| | Process Value Filter Time
| | Setpoint High Limit
| | Setpoint Low Limit
| | Output High Limit
| | Output Low Limit
| Control Parameters
| | Gain
| | Reset
| | Rate
| | Bypass
| | Balance Time
| Feed Forward Control
| | Feed Forward Scale
| | | EU at 100%
| | | EU at 0%
| | | Units Index
| | | Decimal
| | Feed Forward Gain
| Tracking
| | Tracking Scale
| | | EU at 100%
| | | EU at 0%
| | | Units Index
| | | Decimal
| Options
| Control Options
| Status Options
| Shed Options
| Back Calculation Hysteresis
Diagnostics/Alerts
| Block Error
| Alert Parameters
|
|
|
Block Alarm
| | Unacknowledged
| | Alarm State
| | Time Stamp
| | Subcode
| | Value
| Alarm Summary
| | Current
| | Unacknowledged
| | Unreported
| | Disabled
| Acknowledge Option
| Alarm Hysteresis
| High High Alarm Set
| | High High Priority
| | High High Limit
High High Alarm
| |
| | | Unacknowledged
| | | Alarm State
| | | Time Stamp
| | | Subcode
| | | Value
| High Alarm Set
| | High Priority
| | High Limit
| | High Alarm
| | | Unacknowledged
| | | Alarm State
| | | Time Stamp
| | | Subcode
| | | Value
| Low Alarm Set
| | Low Priority
| | Low Limit
| | Low Alarm
| | | Unacknowledged
| | | Alarm State
| | | Time Stamp
| | | Subcode
| | | Value
| Low Low Alarm Set
| | Low Low Priority
| | Low Low Limit
| | Low Low Alarm
| | | Unacknowledged
| | | Alarm State
| | | Time Stamp
| | | Subcode
| | | Value
| Deviation High Alarm Set
| | Deviation High Priority
| | Deviation High Limit
| | Deviation High Alarm
| | | Unacknowledged
| | | Alarm State
| | | Time Stamp
| | | Subcode
| | | Value
| Deviation Low Alarm Set
| | Deviation Low Priority
| | Deviation Low Limit
| | Deviation Low Alarm
| | | Unacknowledged
| | | Alarm State
| | | Time Stamp
| | | Subcode
| | | Value
| Update Event
| Unacknowledged
| Alarm State
| Time Stamp
| Subcode
| Value
Others
| Grant Deny
| Grant
| Deny
Query Device
Standard parameters
FA0909.ai
Note: Parameter name may differ according to a tool or host.
