Table 5.11 View Objects for Resource Block
Relative
Index
Parameter
Mnemonic
VIEW_
1
VIEW_
2
VIEW_
3
VIEW_
4
1 ST_REV 2 2 2 2
2 TAG_DESC
3 STRATEGY 2
4 ALERT_KEY 1
5 MODE_BLK 4 4
6 BLOCK_ERR 2 2
7 RS_STATE 1 1
8 TEST_RW
9 DD_RESOURCE
10 MANUFAC_ID 4
11 DEV_TYPE 2
12 DEV_REV 1
13 DD_REV 1
14 GRANT_DENY 2
15 HARD_TYPES 2
16 RESTART
17 FEATURES 2
18 FEATURE_SEL 2
19 CYCLE_TYPE 1
20 CYCLE_SEL 2
21 MIN_CYCLE_T 4
22 MEMORY_SIZE 2
23 NV_CYCLE_T 4
24 FREE_SPACE 4
25 FREE_TIME 4 4
26 SHED_RCAS 4
27 SHED_ROUT 4
28 FAIL_SAFE 1 1
29 SET_FSAFE
30 CLR_FSAFE
Relative
Index
Parameter
Mnemonic
VIEW_
1
VIEW_
2
VIEW_
3
VIEW_
4
31 MAX_NOTIFY 4
32 LIM_NOTIFY 1
33 CONFIRM_TIME 4
34 WRITE_LOCK 1
35 UPDATE_EVT
36 BLOCK_ALM
37 ALARM_SUM 8 8
38 ACK_OPTION 2
39 WRITE_PRI 1
40 WRITE_ALM
41 ITK_VER
42 SOFT_REV
43 SOFT_DESC
44 SIM_ENABLE_MSG
45 DEVICE_STATUS_1 4
46 DEVICE_STATUS_2 4
47 DEVICE_STATUS_3 4
48 DEVICE_STATUS_4 4
49 DEVICE_STATUS_5 4
50 DEVICE_STATUS_6 4
51 DEVICE_STATUS_7 4
52 DEVICE_STATUS_8 4
53
SOFTDWN_PROTECT
1
54
SOFTDWN_FORMAT
1
55 SOFTDWN_COUNT 2
56
SOFTDWN_ACT_AREA
1
57
SOFTDWN_MOD_REV
16
58 SOFTDWN_ERROR 2
Total bytes 22 30 73 35
