YOKOGAWA digitalYEWFLO Series User Manual

<5. CONFIGURATION>
5-9
IM 01F06F00-01EN
Table 5.12 View Objects for Transducer Block
Relative
Index
Parameter Mnemonic
VIEW_1 VIEW_2
VIEW_3
1
st
VIEW_3
2
nd
VIEW_3
3
rd
VIEW_3
4
th
VIEW_4
1
st
VIEW_4
2
nd
VIEW_4
3
rd
VIEW_4
4
th
VIEW_4
5
th
VIEW_4
6
th
1 ST_REV 2 2 2 2 2 2 2 2 2 2 2 2
2 TAG_DESC
3 STRATEGY 2
4 ALERT_KEY 1
5 MODE_BLK 4 4
6 BLOCK_ERR 2 2
7 UPDATE_EVT
8 BLOCK_ALM
9
TRANSDUCER_
DIRECTORY
10 TRANSDUCER_TYPE 2 2 2 2
11 XD_ERROR 1 1
12
COLLECTION_
DIRECTORY
13 PRIMARY_VALUE_TYPE 2
14 PRIMARY_VALUE 5 5
15
PRIMARY_VALUE_
RANGE
11
16 CAL_POINT_HI 4
17 CAL_POINT_LO 4
18 CAL_MIN_SPAN 4
19 CAL_UNIT 2
20 SENSOR_TYPE 2
21 SENSOR_RANGE 11
22 SENSOR_SN 4
23 SENSOR_CAL_METHOD 2
24 SENSOR_CAL_LOC 32
25 SENSOR_CAL_DATE 7
26 SENSOR_CAL_WHO 32
27 LIN_TYPE 1
28 SECONDARY_VALUE 5
29
SECONDARY_VALUE_
UNIT
2
30 PRIMARY_FTIME 4
31 TERTIARY_VALUE 5
32 TERTIARY_VALUE_UNIT 2
33 LIMSW_1_VALUE_D 2
34 LIMSW_1_TARGET 1
35 LIMSW_1_SETPOINT 4
36
LIMSW_1_ACT_
DIRECTION
1
37 LIMSW_1_HYSTERESIS 4
38 LIMSW_1_UNIT 2
39 LIMSW_2_VALUE_D 2
40 LIMSW_2_TARGET 1
41 LIMSW_2_SETPOINT 4
42
LIMSW_2_ACT_
DIRECTION
1
43 LIMSW_2_HYSTERESIS 4
44 LIMSW_2_UNIT 2
45 ALARM_PERFORM 2
46 ARITHMETIC_BLOCK 1 1
47 SENSOR_STATUS 1 1
48 FUNCTION 1 1
49 FLUID_TYPE 1 1
