YOKOGAWA EJA210E User Manual

54
IM01C25A01-01E
Revision Information
Title : EJXandEJA-ESeries
  DifferentialPressureandPressureTransmittersInstallationManual
ManualNo. : IM01C25A01-01E
Edition Date Page RevisedItem
1st Aug. 2009 Newpublication
2nd Apr. 2010 7 to 14 2.4 Addlimitationofambienttemperaturefor/HE.
3rd Oct. 2010 1,5and15
1
2
3
30 to 31
41 to 43
 AddEJX610AandEJX630A.
1. Add HART 7 manual.
1. Add note for wet location in (c).
3. AddEJX630A.
5.4 Modifypicturesofcablegland.
8. AddparametersforEJX900A(Dev.rev.2).
4th Aug. 2011 1
14
27
28
36
37
40
1. ModifyTable1.1.
2.4.3 Alterthenote(*1)fornameplate.
5.2.2 Changethepictureofcongurationtool.
5.2.4 Add note (*3).
7 AddHARTprotocolrevision7toNOTE.
7 ModifyTable7.2.
8 AddHARTprotocolrevision7andEJX910A/EJX930AtoNOTE.
 DeletetheMenuTreeforEJX910A/EJX930A.
5th Mar. 2012 ReviseCD-R(Ed5).
6th Aug.2012 ―
1
10 to 15
17
42-46
AddEJA-Eseries.
AddtableforEJAtoTable1.1.Addnoteforrepresentationofmodelname.
Revise ATEX approval.
AddmodelstoPEDtable.
Add parameters and notes.
7th Jun.2013 ―
7
13 to 14
16 and 17
20
AddPROFIBUSPA.
Add note for multiple approval option.
ReplaceATEXtypenbyATEXExic.
AddEJA110Ewith/HGtoPEDtable.
Modifynoteforinstallationheight.
8th June2014 2
8
17
28 to 34
28
37 to 42
1. Addnoteforsymbols.
2.4.2 RevisecategoryforCSANonincendive.
2.7 Update safety requirement standard.
5. Revisedrawingsandsymbolsforterminal.
5.2.1 Add note for power supply.
6.3 Add local parameter setting function.
9th Oct. 2014 8
10
13
16 to 17
17
29
30
33
36
40
41
42
2.4.1 Add information for 1 to 5 V output.
2.4.2 Add information for 1 to 5 V output.
2.4.3 Add information for 1 to 5 V output.
2.4.5 AddEPLcode.Reviseapplicablestandard.Addinformationfor1to5
Voutput.Addnoteforelectrostaticcharge.Addelectricalconnection.
2.5 AddstandardforPROFIBUS.
5.2 Add Figure 5.2 Terminal.
5.2.1 Add information for 1 to 5 V output.
5.3.1 Add information for 1 to 5 V output.
5.6 Addapplicability.
6.3.1 Add “10.Device information”
6.3.3 Addnoteinthegure.Addmethodofcancel/save.Delete6.3.4to
6.3.11
7. CorrectAL31outputoperation.
