YOKOGAWA OX100 User Manual

Appendix
App.-1
IM 11M10A01-01E
uAppendix1.SamplingUnit
 K9424GASamplingUnitforOX100/102
ThissamplingunitisdesignedfortheOX100SeriesOxygenAnalyzersandisusedwherea
samplegascontainsasmallamountoforganicsolvent(e.g.isopropylalcohol),suchasinreow
furnaces.
Thesamplingunitcomprisestwomembranelterstoeliminatedustandmist,asuctionpumpto
drawasamplegas,anactivatedcarbonltertoeliminateorganicsolvents,andaowmeterto
monitorsamplegasowrates.
NOTE
If repair is required, the is equipment will need to be retuned to the factory. For repair or
maintenance, contact your Yokogawa representative.
1.Specications
Pressure at sampling point : 1013±40 hPa
Pressure at sample outlet : 1013±40 hPa
Gas temperature : 50°C max.
Organic solvent content : ppm to a few percentage level of isopropyl alcohol (IPA)
equivalent
Dust content : 5 mg/Nm3 max.
Life expectancy of activated carbon: Approx. 1L of absorbed IPA volume
Power supply : 100 V, 50/60 Hz
Piping connection : Rc1/4
Operating envioronment temperature range: 0 to 40°C
Lifeofmembraneletr:Whenspeciedowisnolongerpossible.Replaceasearlyaspossible.
Pump life : Approximately one year when used eight hours a day.
Included Accessories
Power cord (1) A1007WD (AC 100 V standard)
Fuse (2) A1109EF (rating 1A)
Instruction Manual (1)
4th Edition : Oct. 23, 2019-00
