YOKOGAWA OX100 User Manual

<2. Installation >
2-8
IM 11M10A01-01E
60°
ø17mm or G3/8 hole
Caution: Sensor is HOT
Figure2.8 InstallationofSensor
2.6 InstallingtheOptionalSamplingUnit(K9424GA)
The sampling unit is a desktop type and should be installed on a stand near the sampling point.
Note the following when installing the unit.
CAUTION
The unit should be installed in places where:
• Ambienttemperatureisintherangeof0to40Candtemperatureuctuationsareminimal.
• Mechanical vibration is negligible.
• Adequatespaceforinspectionandmaintenance,suchasreplacinglterelement,is
secured.
• The unit should be securely mounted on a stand
The sampling unit incorporates a suction pump, which requires power supply of 100 V AC.
Thesamplingunitcomprisesmembranelters,suctionpump,owmeterandactivatedcarbon
ltertoabsorborganicsolvents.Whenasamplegascontainsorganicsolvents,usethissampling
unittolteroutsuchsolvents.Theexpectedlifeoftheactivatedcarbonlterisapproximately50
hourswhenasamplegascontains500ppmofisopropylalcoholandowsat500ml/min.
Used eight hours a day, suction pump life will be approximately one year.
