IM 12B6C2-E-H
30
7. SERVICE MODE
7-1. Introduction
Generally speaking their is no necessity to
adjust the settings of the service section. All
parameters are pre-programmed to values
(so-called defaults) enabling you to start
working immediately.
The advanced functions available through
this section are only needed in some specific
applications. This fine-tuning of the in stru-
ment gives a superior performance over
analogue 2-wire instruments.
If a function has to be adjusted it is called up
with the code mentioned. Having selected
the code then give you the possibility to eit-
her activate or adjust the values for this
function. After this you will return to the entry
point to make other adjustments or go back
to the measuring status.
If errors are made during the programming
process, these will be indicated, no action
will be taken and you can start the program-
ming again
Code Routine Use Chapter
01 Temperature compensation Process comp. on/off
and units Select °C or °F 7-3
02 Temperature sensors Select sensor type 7-4
03 Sensor checking Choose impedance, asymmetry
or slope 7-5
04 Display resolution Select 0,1 of 0,01 pH 7-6
05 Signalling of fail condition Switch burn-out signal 7-7
06 Stabilisation check Adjust parameters 7-8
07 Auto return function Switch on or off 7-9
08 Buffer table (7) Program user tables 7-10
09 Buffer table (4) Program user tables 7-10
10 Buffer table (9) Program user tables 7-10
11 Temperature adjustment Correct cable sensor 7-11
12 Manual adjustment ITP, slope Settings for non-standard
and asymmetry potential electrodes 7-12
33 Password activation Protecting operation levels 7-13
55 Restore default values Erase all user programmed values 7-14
