YOKOGAWA RAMC User Manual

<10. EXPLOSION-PROTECTED TYPE INSTRUMENTS>
10-16
IM 01R01B02-00E-E 12th edition October 01, 2014 -00
All Rights Reserved. Copyright © 2003, Rota Yokogawa
Limit switches FM intrisically safe (2)
Dieses Dokument enthält sicherheitsrelevante Angaben. Es darf nicht ohne Absprache mit dem Normenfachmann geändert werden!
This document contains safety-relevant information. It must not be altered without the authorization of the norm expert!
Confidential according to ISO 16016 Only valid as long as released in EDM or with a valid production documentation! scale: 1:1 date: 2010-jun-03
respons. US.DRL
approved US.DWR
116-0165F
Twinsburg
Control Drawing
NAMUR SENSORS – FM
change notice
150- 1915
norm US.GAP sheet 7 of 8
NJ 15-30GM-N...
140 100 76 91 100 73 88 100 62 77 81 54 63 63
NJ 25-50-N...
150 140 73 88 100 69 84 100 51 66 80 39 54 61
NJ 20-40-N...
140 140 73 88 100 69 84 100 51 66 80 39 54 61
Table 10 – INDUCTIVE RING SENSORS
Typ 1 Typ 2 Typ 3 Typ 4
Ui = 16 V Ui = 16 V Ui = 16 V Ui = 16 V
Ii = 25 mA Ii = 25 mA Ii = 52 mA Ii = 76 mA
Pi = 34 mW Pi = 64 mW Pi = 169 mW Pi = 242 mW
Model
Ci/
nF
Li/
µH
T6 T5 T4-T1 T6 T5 T4-T1 T6 T5 T4-T1 T6 T5 T4-T1
RC10-a-N3a 90 120 75 90 100 70 85 100 55 70 90 N/A N/A N/A
RC10-a-N0a 150 100 75 90 100 70 85 100 55 70 90 N/A N/A N/A
RC15-a-N0-a 150 100 75 90 100 70 85 100 55 70 90 N/A N/A N/A
RC15-a-N3a 90 70 75 90 100 70 85 100 55 70 90 N/A N/A N/A
RJ10-Na 30 20 75 90 100 70 85 100 55 70 90 N/A N/A N/A
RJ10-a-Na 30 20 75 90 100 70 85 100 55 70 90 N/A N/A N/A
RJ10-Bia 90 20 75 90 100 70 85 100 55 70 90 N/A N/A N/A
RJ10-a-Bia 90 20 75 90 100 70 85 100 55 70 90 N/A N/A N/A
RJ15-Na 130 20 75 90 100 70 85 100 55 70 90 N/A N/A N/A
RJ15-a-Na 130 20 75 90 100 70 85 100 55 70 90 N/A N/A N/A
RJ15-Bia 90 50 75 90 100 70 85 100 55 70 90 N/A N/A N/A
RJ15-a-Bia 90 50 75 90 100 70 85 100 55 70 90 N/A N/A N/A
RJ21-Na 30 25 75 90 100 70 85 100 55 70 90 N/A N/A N/A
RJ21-Bia 70 50 75 90 100 70 85 100 55 70 90 N/A N/A N/A
RJ43-Na 40 50 75 90 100 70 85 100 55 70 90 N/A N/A N/A
TABLE 11 – INDUCTIVE SLOT SENSORS
Typ 1 Typ 2 Typ 3 Typ 4
Ui = 16 V Ui = 16 V Ui = 16 V Ui = 16 V
Ii = 25 mA Ii = 25 mA Ii = 52 mA Ii = 76 mA
Pi = 34 mW Pi = 64 mW Pi = 169 mW Pi = 242 mW
Model
Ci/
nF
Li/
µH
T6 T5 T4-T1 T6 T5 T4-T1 T6 T5 T4-T1 T6 T5 T4-T1
SC2-N0a 150 150 55 67 95 48 60 88 23 35 63 6 18 46
SC3.5a-N0a 150 150 56 68 96 49 61 89 28 40 68 13 25 53
SC3.5-N0-Ya 150 150 55 67 95 48 60 88 23 35 63 6 18 46
SJ1.8-N-Ya 30 100 73 88 100 67 82 100 45 60 78 30 45 57
SJ2-Na 30 100 56 68 96 49 61 89 28 40 68 13 25 53
SJ2-SNa 30 100 73 88 100 66 81 100 45 60 78 30 45 57
SJ2-S1Na 30 100 73 88 100 66 81 100 45 60 78 30 45 57
SJ2.2-Na 30 100 73 88 100 67 82 100 45 60 78 30 45 57
SJ3.5-a-Na 50 250 56 68 96 49 61 89 28 40 68 13 25 53
SJ3.5-H-a 50 250 73 88 100 66 81 100 45 60 89 30 45 74
SJ3.5-SNa 30 100 73 88 100 66 81 100 45 60 89 30 45 74
SJ3.5-S1Na 30 100 73 88 100 66 81 100 45 60 89 30 45 74
SJ5-a-Na 50 250 56 68 96 49 61 89 28 40 68 13 25 53
SJ5-Ka 50 550 55 67 95 48 60 88 25 37 65 9 21 49
SJ10-Na 50 100 55 67 95 48 60 88 25 37 65 9 21 49
SJ15-Na 150 1200 55 67 95 48 60 88 25 37 65 9 21 49
SJ30-Na 150 1250 55 67 95 48 60 88 25 37 65 9 21 49
