9. Technical Data
9.1 Model- and suffix-codes
Model Suffix code Description Restrictions
RAMC01
RAMC23
RAMC02
RAMC03
RAMC04
RAMC05
RAMC06
RAMC08
RAMC09
RAMC10
RAMC12
RAMC15
RAMCNN
Size DN 15 (½ inch)
Size DN 20 (¾ inch)
Size DN 25 (1 inch)
Size DN 32 (1¼ inch)
Size DN 40 (1½ inch)
Size DN 50 (2 inch)
Size DN 65 (2½ inch)
Size DN 80 (3 inch)
3½ inch
Size DN 100 (4 inch)
Size DN 125 (5 inch)
Size DN 150 (6 inch)
Without measuring tube
for D4, D6, A1, A2, A3, T4, R4, T6, G6
for D4, D6, A1, A2, A3, T4, R4, T6, G6
for D4, D6, A1, A2, A3, S2, S4, S5, T4,
R4, T6, G6
for D4, D6, A1, A2, A3, S4, T6, G6
for D4, D6, A1, A2, A3, S4, S5, T6, G6
for D4, D5, D6, A1, A2, A3, S2, S4,T4, R4
for D4, D5, A1, A2, A3, S2, S4, T4, R4,
T6, G6
for D4, D5, A1, A2, A3, S2, S4
for A1, A2
for D2, D4, A1, A2, S4, S4
for D2, A1, A2, S2
for D2, A1, A2
Process
connection
-D2
-D4
-D5
-D6
-A1
-A2
-A3
-T6
-G6
-R4
-S2
-S4
-T4
-S5
-NN
EN ange PN 16, process connection dimen-
sion + facing acc. EN 1092-1 Form B1
EN ange PN 40, process connection dimen-
sion + facing acc. EN 1092-1 Form B1
EN ange PN 63, process connection dimen-
sion + facing acc. EN 1092-1 Form B1
EN ange PN 100, process connection dimen-
sion + facing acc. EN 1092-1 Form B1
ASME ange class 150, process connection
dimension
+ facing acc. ASME B 16.5
ASME ange class 300, process connection
dimension
+ facing acc. ASME B 16.5
ASME ange class 600, process connection
dimension
+ facing acc. ASME B 16.5
NPT PN 40 female thread
G PN 40 female thread
Rp removable female thread
Thread acc. DIN 11851
Tri- clamp PN 10, PN16 acc. DIN 32676
NPT removable female thread
Flange Rosista PN 10
Without process connection
Material of wetted
parts
SS
PF
NN
Stainless steel
Teon lining
Without wetted parts Only with RAMCNN
Cone / Float -nnnn
-NNNN
See tables 10 ... 12
Without measuring tube / without oat Only with RAMCNN
Indicator / Transmitter -T
-E
-G
-H
-N
Indicator local
Indicator electronic
Indicator electronic with Probus PA
Indicator electronic with HART 5
Without indicator
Only with output 429
Only with output 424
Only with housing NN
Housing / Type 90
91
NN
Housing round blanc; SS
Housing round yellow; Al
Without housing Only with indicator N
Power supply / Output 240
244
140
144
430
434
424
429
NNN
230 V AC ; 4- wire; 0-20 mA
230 V AC ; 4- wire; 4-20 mA
115 V AC ; 4- wire; 0-20 mA
115 V AC ; 4- wire; 4-20 mA
24 V DC; 3- wire; 0-20 mA
24 V DC; 3- wire; 4-20 mA
24 V DC; 2- wire; 4-20 mA
Probus PA; 9 ... 32 V DC
Without power supply
Only with indicator E; not with limit switches
Only with indicator E; not with limit switches
Only with indicator E; not with limit switches
Only with indicator E; not with limit switches
Only with indicator E
Only with indicator E
Only with indicator E, H
Only with indicator G; not with limit switches
Only with indicator T or N
