6.2.1 Selection of indication function (F11)
The function F11 selects the display’s indication function.
The following indications can be set: ow rate, totalizer, % value or temperature.
At the factory the display is preset to totalizer indication.
Description Selection Key Indication
Change to setting mode Enter
Display mode
F1-
Setting function
Selection
or
or
or
Flow rate
Totalizer
%
Temperature
Enter
Enter
Enter
→
Enter
2 x →
Enter
3 x →
Enter
F11
F11 -1
F11
F11 -2
F11
F11 -3
F11
F11 -4
F11
Back to display mode
↑
↑
F1-
Display mode
Note: If you press “↑” instead of “Enter”, you can return from the selected point to the previous menu without
activating the displayed parameter.
When selecting “Flow rate” the measuring unit is set with function F12 and F13. When selecting “Totalizer” the
measuring unit is set with F12. If % indication is selected, F12 and F13 have no effect. The internal totalizer is
updated, if “Flow rate” or “Counter” is selected. In case of setting to “%” the internal counter is not updated
and keeps its previous value.
If "Temperature" is selected the unit can be set by function F15. The indicated value is the temperature in the
indication unit.
After changing the indicating function and measuring units the corresponding measuring unit label should be
xed on the right side next to the display.
