6.2.7.4 Calculation of pulse rate
Concerning the nal ow-value (Qmax ), which was declared in the customers order, the pulse rate is
calculated in factory and is written onto the sheet ´Data of Pulse Output (Option /CP)´, which is included. This
value can be transferred to a blank label of the also included sheet with unit-stickers and then xed on the
scale. After changing the ow rate unit with F12 the pulse rate must be recalculated.
Calculation of pulse rate :
· Read the value of Qmax from the scale or recalculate it.
· Search for the concerning range in the rst row of the table below.
· Read the concerning pulse rates in the second and third row.
· The measuring unit is equal to the ow
Maximum ow Qmax
without unit
Pulse rate for F34-2
without unit
Pulse rate for F34-3
without unit
Qmax ≤ 1
1 < Qmax ≤ 10
10 < Qmax ≤ 100
100 < Qmax ≤ 1000
1000 < Qmax ≤ 10000
10000 < Qmax ≤ 100000
0.0001
0.001
0.01
0.1
1
10
0.001
0.01
0.1
1
10
100
e.g..: Final value (Qmax ) = 400 m3/h
→ Pulse rate 0.1 m
3
for F34-2 and 1 m
3
for F34-3
• The factory default is F34 -2 (solution : 1 last digit).
• After Master Reset F34 -1 (Pulse output not active) is selected.
• After changing the ow rate unit with F12 the pulse-register is deleted and the pulse rate is automatically
redened according to the new unit.
• After totalizer Reset with F14 the pulse output does not change.
• When changing the indication with F11 -3 to ´%´, the totalizer stops and the pulse output is switched off.
• After switching power on one pulse is generated at the output.
• For 2- respectively 3-wire-units the function F34 is not supported.
