FLAME PROOF AND DUST PROOF RAMC
Flame proof and dust proof RAMC with ATEX-
certicate (option /KF1):
Certicate :
IBExU 05 ATEX 1086
Flame proof :
Ex d IIC T1 ... T6 Gb ; group II ; category 2G
Dust proof :
Ex tb IIIC TX Db IP6X; group III ; category 2D
Max. surface temperature TX :corresp. process temperature
Housing :
Painted aluminium casting, type 91
Output signal (with electronic transmitter -E, -H) :
4–20 mA (2- wire unit, 3- wire unit) ; 0-20 mA (3- wire unit)
Power supply (with electronic transmitter -E, -H) :
2- or 3- wire unit
Limit switches :
Options /K1 to /K10 possible
Ambient temperature :
-20 °C to 60 °C
Minimum process temperature :
-20°C
Threads for cable glands :
- M20x1.5 (standard)
- ½” NPT (option /A5)
Temperature classication :
Table 8
see table 8
Flame proof and dust proof RAMC with IECEx-
certicate (option /EF1):
Certicate :
IECEx IBE12.0007
Flame proof :
Ex d IIC T1 ... T6 Gb ; group II ; category 2G
Dust proof :
Ex tb IIIC TX Db IP6X; group III ; category 2D
Max. surface temperature TX :corresp. process temperature
Housing :
Painted aluminium casting, type 91
Output signal (with electronic transmitter -E, -H) :
4–20 mA (2- wire unit, 3- wire unit) ; 0-20 mA (3- wire unit)
Power supply (with electronic transmitter -E, -H) :
2- or 3- wire unit
Limit switches :
Options /K1 to /K10 possible
Ambient temperature :
-20 °C to 60 °C
Minimum process temperature :
-20°C
Threads for cable glands :
- M20x1.5 (standard)
- ½” NPT (option /A5)
Temperature classication :
Table 8
see table 8
Flame proof and dust proof RAMC with PESO-
certicate (India) :
Option /KF1 must be selected. PESO- certicate is available
at your Yokogawa Sales Office.
Flame proof and dust proof RAMC with KOSHA-
certicate (Korea) :
Same data as IECEx- certied type (/EF1).
Flame proof RAMC with EAC- certicate (Russia,
Belorussia , Kazakhstan ) (option /GF1) :
Certicate :
RU С-DЕ.ГБО8.В.00317
Flame proof :
1Ex d IIC T1 ... T6
Housing :
Painted aluminium casting, type 91
Output signal (with electronic transmitter -E, -H) :
4–20 mA (2- wire unit, 3- wire unit) ; 0-20 mA (3- wire unit)
Power supply (with electronic transmitter -E, -H) :
2- or 3- wire unit
Limit switches :
Options /K1 to /K10 possible
Ambient temperature :
-40 °C to 60 °C
Minimum process temperature :
-20°C
Threads for cable glands :
- M20x1.5 (standard)
- ½” NPT (option /A5)
Temperature classication :
see table 8
Flame proof and dust proof RAMC with NEPSI-
certicate (China) (option /NF1) :
Certicate :
GYJ13.1018X
Flame proof :
Ex d IIC T1~T6 Gb
Dust proof :
DIP A20 T
A
, T1~T6 IP67
Max. surface temperature T
A
: corresponding process
temperature
Housing :
Painted aluminium casting type 91
Output signal (with electronic transmitter -E, -H) :
4–20 mA (2- wire unit, 3- wire unit) ; 0-20 mA (3- wire unit)
Power supply (with electronic transmitter -E, -H) :
2- or 3- wire unit
Limit switches :
Options /K1 to /K10 possible
Ambient temperature :
-20 °C to 60 °C
-20 °C to 55 °C (for use in zone 20)
Minimum process temperature :
-20°C
Threads for cable glands :
- M16x1.5 (standard)
- ½” NPT (option /A5)
Temperature classication :
Table 8
Temp.
class
Max. Process temperature
No extension On Extension On extension
with insulation
T6 85°C 85°C 85°C
T5 100°C 100°C 100°C
T4 120°C 135°C 135°C
T3 120°C 200°C 200°C
T2 120°C 300°C 300°C
T1 120°C 370°C 350°C
