YOKOGAWA RAMC User Manual

<9. TECHNICAL DATA>
9-16
IM 01R01B02-00E-E 12th edition October 01, 2014 -00
All Rights Reserved. Copyright © 2003, Rota Yokogawa
RAMC Flange dimensions
Table 9-14
Inner diameter of stainless steel anges Inner diameter of anges with PTFE- lining
Pos.
*)
EN-ange without groove ASME-ange Rosita-
ange
Pos.
*)
EN- ange ASME-
age
Size
Du
mm
Do
mm
Size
Du
mm
Do
mm
Du=Do
mm
Size Size
Du = Do
mm
1 DN15-DN50 20.7 20.7 ½´´ - 1´´ 20.7 20.7 20.7 ---- ---- ---- ----
2
DN15-DN50 29.5 29.5
½´´ 20.7 20.7
29.5 2 DN15-DN25 ¾´´ - 1´´ 23.5
¾´´ - 2´´ 29.5 29.5
3
DN25-DN50 45.2 45.2
1´´ 32.2 32.2
45.2 3 DN25-DN50
1¼´´
- 1½
36.0
1¼´ - 2´´
45.2 45.2
4
DN50-DN100 62.0 76.0
2´´ 62.0 65.5
----- 4 DN50-DN80 2½´´ - 3´´ 66.0
2½´´ - 3´´ 62.0 76.0
5 DN80-DN150 94.0 94.0 3´´ - 6´´ 94.0 94.0 ----- 5 DN80-DN100 3½´´ - 4´´ 82.0
6 DN100-DN150 116.0 116.0 4´´ - 6´´ 116.0 116.0 ----- 6 DN100 4´´ 110.0
*)
see table 9.10, 9.11, 9.12
Fig. 9-5 RAMC type 91 and option /A16 and /T2 Fig. 9-6 RAMC with connection R4 / T4
T25.EPS
T26.EPS
