YOKOGAWA SC200 User Manual

SC 200 S
V
out
= 14.4 V max.
I
out
= 129 mA max.
C ext = 1 µF max
L ext = 2.3 mH max.
31.5 Vmax
4-20 mA
+
–
•
•
11 12 14 13 17 15 16
IM 12D7B2-E-H
37
8-2. FM
connecting cables
such as (but not limited to):
WU40-LH18 WU40-LH2
WU40-LH5
10 meter Maximum
HAZARDOUS LOCATION
FMRC-Approved Barrier
To be installed in accordance with ANSI/RP 12.6 and NEC requirements
Maximum safe area voltage should not exceed 250 V
RMS
NON HAZARDOUS LOCATION
Class I, Division I, Groups ABCD
Vmax = 31.5 V
Imax = 93.3 mA
Ci = 5 nF
Li = 16.5 uH
ControlDrawing for EXA 200 instruments
1 conductivity sensor with integral SC41-SP34
temperature sensor such as (but SC49-FP08
not limited to) SC41-SP24
SC41-EP14
SC41-EP04
These are all passive sensor to be regarded as "simple apparatus"
i.e. devices which do neither store nor generate voltage over 1.2 V,
currents over 0.1 A, power over 25 W or energy over 20 mJ
