IM 12D7B2-E-H
2. SPECIFICATIONS
2-1. General specifications
A. Intrinsic safety (model SC200S only)
- BASEEFA : Certified by and meets the requirements
of EEx [ia] ib IIC T4 of CENELEC
Certificate No.: 89C2379.
- FM : For IS CL1, DIV1, GP ABCD
T3B for TA-30 to 70˚C
T4 for TA-30 to 40˚C
Approval report: J.I. 1Y1A7.AX
- CSA : For Ex[ia] Class 1, Div. 1, Groups C
and D, T4A
Approval file: LR 102851-1
B. Indicating range : 0.055µS/cm to 2000 mS/cm at 25˚C
reference temperature with cell-con-
stants between 0.01 to 10 cm
-1
C. Transmission signal : 4 - 20 mA DC; maximum load.550 Ω.
D. Transmission range : User programmable to any range within
the indicating range with a maximum of
60% zero suppression.
A user programmable output table can
be set up in 21 steps.
E. Power supply
- Model SC200G : 17 to 40 V DC, dependent on load.
- Model SC200S :
17 to 31,5 V DC, powered from a certified
zener barrier or isolated power supply
F. Climatic condition
- Ambient temperature : -10 to +55 ˚C(10 to 130°F)
- Storage temperature : -30 to +70 ˚C (-20 to 160°F)
- Relative humidity : 10 to 90%
- Weather protection : Rain and dust-tight to IP65 (NEMA 4X)
- Interference protection : EMI Class B
RFI less than 2% at 5 V/m for
20 MHz to 1 GHz.
G. Display method : Custom liquid crystal display.
- Main display : 31/2digit, 12.5 mm high.
- Message display : 6 alphanumeric characters, 7 mm.
- Special fields : Flags for status indication.
: Units: µS/cm, mS/cm.
: Key prompts: YES, NO, ^, >, ENT
H. Keys : 6 keys operated through the flexible win-
dow with tactile feedback and one hid-
den key behind the front cover.
I. Housing
- Body material : Cast aluminium with chemical resistant
coating.
- Window : Flexible poly carbonat.
- Colours used : Moss green/ off-white.
- Cable glands : Polyamide
- Cable entries : Two glands PG 16 (
1
/
2
” NPT adapter for
US Model).
Hose connection optional.
- Terminals : For maximum 2.5mm
2
cable (cable
finishings preferred).
- Earth connection : For external ground.
J. Mounting possibilities
- Bracket mounting : Two M6 bolts, 9 mm length.
Wall, or pipe mounting by the optional
mounting kit, panel mounting by self tap-
ping screws.
K. Shipping details
- Dimensions : 162 x 178 x 115 mm
(6.5 x 7 x 4.5”)
- Package : 290 x 225 x 170 mm
(11.5 x 8.9 x 6.7”)
- Weight : approx. 2,5 kg (5 Ibs)
L. Safety and security
- Data protection : Non volatile memory(EEPROM).
- Data backup : All data is stored 3 times.
- Interference test : according to IEC 801.
- Power down : no effect, reset to measurement.
- Operation : All 3 levels can be protected with a 3
digit passcode.
2
