YOKOGAWA SMARTDAC+ GX10 User Manual

2-5
IM 04L51B01-01EN
Operating the GX/GP
1
2
3
4
5
App
Index
Starting Recording
1 Press MENU.
The menu screen appears.
2 Tap Recording.
The record start screen appears.
3 Tap Batch name-No. and Lot No., and set each item.
4 If necessary, tap Batchtextfield(text) or Batch comment to set them.
Tap Edittexteld or Editcomment to display Batch texteld or Batch comment in the Record
start screen.
The text elds that you specify here will only be saved to the measurement data le that you are
about to start recording to. The text elds that you have set from the setting menu will not change.
Switches between batch comment
and batch text
5 Tap Rec+Math, Rec+Math(Mathreset), or Record.
Recording starts. The recording status icon in the status display section changes from stopped to
started.
If computation is not in progress, you can select Rec+Math or Rec+Math(Math
reset).
On Models without the math function (/MT option), tap Start.
Operation complete
• You can also use the START/STOP key.
For details, see page 2-1 in section 2.1.1, “Starting and Stopping Recording”.
2.1 Starting and Stopping Recording and Computation
