YOKOGAWA SMARTDAC+ GX10 User Manual

App-10
IM 04L51B01-01EN
Note
• File status
Complete: Completed. (100 manual sample data entries have been stored, and the file is
closed.)
Progress: Data is being added. (The number of stored data entries has not reached 100 files,
and the file is open.)
Decrease: Corrupted. (Some of the manual sample data in the file are missing.)
• Output when channel data is in the condition shown in the table below
Data Condition Data Handling Output
Error Error (Space)
+Overrange +Over Value indicated for
PlusOver in the Extra
Data information header
section
+Burnout
+Display over
+Computation over
–Overrange –Over Value indicated for
MinusOver in the Extra
Data information header
section
–Burnout
–Display over
–Computation over
• A new manual sampled data file is created in the following cases.
• The range of an I/O channel configured as a manual sampling recording channel was changed
from some range other than Skip to Skip.
• The range of an I/O channel configured as a manual sampling recording channel was changed
from Skip to some range other than Skip.
• A math or communication channel configured as a manual sampling recording channel was
changed from On to Off or from Off to On.
• The unit of a channel configured as a manual sampling recording channel was changed.
• When the settings of a manual sampling recording channel are changed.
• When an AI channel configured as a manual sampling recording channel is changed from the DI
range (calculation is not set to linear scaling) to some other range, or vice versa.
• When a DI channel configured as a manual sampling recording channel is changed from linear
scaling calculation to some other setting, or vice versa.
• When the decimal place of a channel configured as a manual sampling recording channel is
changed.
Appendix 3 Text File Data Format
