4-62
IM 04L51B01-01EN
Unit I/O channel information Start register Endregister Register type Remarks
Expandable
I/O 3
Channel 3501 information 450801 450840 16-bit signed
integer
High and low limit range, unit,
tag name writing not allowed
0 if it does not exist.
Channel 3502 information 450841 450880
| | |
Channel 3510 information 451161 451200
Expandable
I/O 4
Channel 4001 information 451201 451240
Channel 4002 information 451241 451280
| | |
Channel 4010 information 451561 451600
Channel 4101 information 451601 451640
Channel 4102 information 451641 451680
| | |
Channel 4110 information 451961 452000
Channel 4201 information 452001 452040
Channel 4202 information 452041 452080
| | |
Channel 4210 information 452361 452400
Channel 4301 information 452401 452440
Channel 4302 information 452441 452480
| | |
Channel 4310 information 452761 452800
Channel 4401 information 452801 452840
Channel 4402 information 452841 452880
| | |
Channel 4410 information 453161 453200
Channel 4501 information 453201 453240
Channel 4502 information 453241 453280
| | |
Channel 4510 information 453561 453600
Expandable
I/O 5
Channel 5001 information 453601 453640
Channel 5002 information 453641 453680
| | |
Channel 5010 information 453961 454000
Channel 5101 information 454001 454040
Channel 5102 information 454041 451080
| | |
Channel 5110 information 454361 454400
Channel 5201 information 454401 454440
Channel 5202 information 454441 454480
| | |
Channel 5210 information 454761 454800
Channel 5301 information 454801 454840
Channel 5302 information 454841 454880
| | |
Channel 5310 information 455161 455200
Channel 5401 information 455201 455240
Channel 5402 information 455241 455280
| | |
Channel 5410 information 455561 455600
Channel 5501 information 455601 455640
Channel 5502 information 455641 455680
| | |
Channel 5510 information 455961 456000
Continued on next page
4.5 Modbus Function and Register Assignments
