Updating Modules
Collectively Updating
Path
GX/GP: Module > Batch update All modules
Description
Version after update
Setup Item Selectable Range or Options Default Value
I/O expansion module — —
I/O module (AI/DI/DO/DIO) — —
Pulse input module — —
I/OExpansionModule
Displays the I/O expansion module version after updating.
I/Omodule(AI/DI/DO/DIO)
Displays the I/O module version after updating.
Pulse input module
Displays the pulse input module version after updating.
Procedure
1 Tap Execute.
A conrmation screen is displayed.
2 Tap OK.
The module rmware is updated.
3 Tap Exit.
A conrmation screen is displayed.
4 Tap Yes.
The GX/GP exits from the update screen and restarts.
Operation complete
Updating Individually
Path
GX/GP: Module > Individual update Main Unit or Unit1 to 6 > Slot0to9*
* GX/GP: Slots 0 to 9
Expandable I/O: Slots 0 to 5
Description
Version
Setup Item Selectable Range or Options Default Value
Current — *
After update — —
Current
Displays the current version of the selected module.
After update
Displays the version of the selected module after updating.
