All Rights Reserved. Copyright © 2012, Yokogawa Electric Corporation
GS 04L51B01-01EN
December 11, 2015-00
AEROSPACEHEATTREATMENT(/AH)
SupportsheattreatmentapplicationAMS2750/
NADCAP.
Schedulemanagementforperiodicallyexecuting
calibrationcorrectioncongurationandthelike.
Incorrectioncoefcientmodeofcalibration
correction,twobiasescanbespecied:one
based on thermocouple and another based on
device
• Numberofmanageableschedules
GX20-1:6
GX20-2: 12
• Calibrationcorrectionmode:
 Off,Linearizerapproximation,Linearizerbias,
correctionfactor
• Numberofsetpoints:2to12
• Noticationcontents
 Title,Noticationmessage,Duedate
Noticationbuzzercanbesounded.
MULTI-BATCHFUNCTION(/BT)
Recordingstart/stopanddatalecreationis
possibleforeachbatch.
• Numberofmulti-batches:
 GX10/GX20-1:max.6,GX20-2:max.12
• Batchsingleoperation:Memorystart/stop,math
reset, message writing
• Batchoverviewoperation:Computationstart/
stop, report start/stop, manual sampling, setup
data save/load
• Scaninterval:500ms,1s,2s,5s(commonto
all batches)
• Datatype:DisplayoreventonlyTriggermode
notavailableforeventdata.
• Recordinginterval:Commontoallbatches
• Datale:Displayoreventdatalecreatedfor
each batch
• Numberofdisplaygroups:
 GX10:6max.perbatch
 Numberofchannelspergroup:10
 GX20-1:6max.perbatch
 Numberofchannelspergroup:20
 GX20-2:12max.perbatch
 Numberofchannelspergroup:20
 Channelsassignedtothedisplaygroupofeach
batch and those set as recording channels are
recordedtodatales.
• Batchsinglesettings:Group,tripline,leheader,
datalename,texteld,batchnumber,lot
number
OPC-UASERVER(/E3)
DataacquiredbytheGXcanbeaccessedthrough
Ethernetcommunicationfromahostsystem
(OPC-UAclient).
• Communication
 Mode:OPC-UAServer
 Encoding:UABinary
 Protocol:OPCUATCP
 Maximumnumberofconnections:3sessions
 Prole MicroEmbeddedDeviceServer
• Security
Type: None
Encryption: None
 Login:Anonymous,Username
• Dataacquisition:Measurementchannel,
computation channel, communication channel
value and alarm status
• Datawriting:Measurementchannel(DOchannel
only), communication channel
• Otheracquiredinformation:Devicename,serial
number, time, device status
• Portnumber:4840(changeable:1to65535)
• Numberofitems:
 GX10:100max.(MonitoredItem/Session)
 GX20:300max.(MonitoredItem/Session)
• Fastestperiod:100ms
• Serviceset:
Discovery FindServers, GetEndpoints
SecureChannel OpenSecureChannel,
CloseSecureChannel
Session CreateSession,ActivateSession,
CloseSession
View Browse,BrowseNext,
TranslateBrowsePathsToNodeIds
Attribute Read,Write
MonitoredItem CreateMonitoredItems,
ModifyMonitoredItems,
DeleteMonitoredItems,
SetMonitoringMode
Subscription CreateSubscription,
ModifySubscription,
DeleteSubscriptions,Publish,
Republish,
SetPublishingMode
SLMPCOMMUNICATION(MitsubishiPLC)(/E4)
Protocolfunctionthatenablesconnectionfrom
a GX to Mitsubishi Electric PLCs without
sequencer programs.
•
Numberofconnectiondestinationservers:16max.
• Readcycle:100ms/200ms/500ms/1s/2s/5s/10s/2
0s/30s/1min
• Communicableinternaldata:
 Specialrelay(SM),specialregister(SD),input
(X), output (Y), internal relay (M), latch relay (L),
annunciator(F),edgerelay(V),linkrelay(B),
dataregister(D),linkregister(W),timercontact
(TS), timer coil (TC), current timer value (TN),
integration timer contact (SS), integration timer
coil (SC), current integration timer value (SN),
counter contact (CS), counter coil (CC), current
counter value (CN), special link relay (SB),
speciallinkregister(SW),directaccessinput
(DX),directaccessoutput(DY),indexregister
(Z),leregister(R,ZR),extendeddataregister
(D),extendedlinkregister(W)
Devicecodeisindicatedinparentheses.
