YOKOGAWA SMARTDAC+ GX10 User Manual

1-54
IM 04L51B01-01EN
1.5 ConfiguringDOChannels(Digitaloutput
channels)
Set the input range and display conditions of DO channels (including the DO channels of DI/
DO modules).
In addition to alarm output, DO output is possible through touch operation (manual
operation).
1.5.1 Setting the Range
Path
GX/GP: MENU key > Browse tab > Setting > Setting menu DO channel settings > Range
Web application: Config. tab > DO channel settings > Channel range (display example:
0701-0706) > Range
Hardware configurator: DO channel settings > Channel range (display example: 0701-
0706) > Range
Description
Setup Item Selectable Range or Options Default Value
First-CH DO channel —
Last-CH DO channel —
First-CH, Last-CH
Set the target channels. The channels that you can specify appear depending on the module
configuration.
Range
Setup Item Selectable Range or Options Default Value
Type Alarm, Manual Alarm
Span Lower 0, 1 0
Span Upper 0, 1 1
Unit
Character string (up to 6 characters,
A
a
#
1
)
—
Type
Set the input type.
To output through touch operation (manual operation), “Changing each value from
monitoring” must be set to On. Refer to page 1-88 in section 1.7.5, “Setting Basic Screen
Items”
For the procedure, see page 2-10 in section 2.2.1, “Displaying Measured Data Using
Waveforms, Numeric Values, Bar Graph, or Custom Display (/CG option) (Trend, digital, bar
graph, and custom displays)”.
Options Description
Alarm Alarm output
Manual Manual output and event action output
SpanLower,Span Upper
Specify 0 or 1. You cannot set the same value to Span Lower and Span Upper.
Unit
Set the unit.
