YOKOGAWA SMARTDAC+ GX10 User Manual

1-59
IM 04L51B01-01EN
Configuring the GX/GP
1
2
3
4
5
App
Index
Scale
Setup Item Selectable Range or Options Default Value
Position GX20/GP20: Off,1,2,3,4,5,6,7,8,9,10
GX10/GP10: Off,1,2,3,4,5,6
1
Position
Set this to set the scale display position of the trend display. Set this to Off to not display
scales.
For display examples, see the scale settings on page 1-23 in section 1.2.3, “Setting the
Display”.
Bar graph
Setup Item Selectable Range or Options Default Value
Base position Lower, Center, Upper Lower
Base position
Set the bar graph base position. This setting is applied on the bar graph display and when
you are displaying the current value on the scale as a bar graph on the trend displays.
For display examples, see the bar graph settings on page 1-23 in section 1.2.3, “Setting the
Display”.
Display characters of each value
Setup Item Selectable Range or Options Default Value
0
Character string (up to 8 characters,
A
a
#
1
)
—
1
Character string (up to 8 characters,
A
a
#
1
)
—
0
Set the character string to display when the measured value is 0.
1
Set the character string to display when the measured value is 1.
For usage examples, see page 1-23 in section 1.2.3, “Setting the Display”.
1.5ConfiguringDOChannels(Digitaloutputchannels)
