YOKOGAWA WT210 User Manual

9-8 IM 760401-01E
Relation between the output item and the D/A output voltage
• Frequency
D/A out
p
u
t
A
pp
rox. 7.5
V
5
.
0
V
0
.
5
V
2.
5
V
Displa
y
ed valu
e
1
0
H
z
0
.
5
H
z
1Hz
1
00
H
z
1 kHz
1
0
kH
z
1
00
kH
z
• Integrated value
D/A out
p
u
t
A
pp
rox. 7.0
V
5
.
0
V
0
Tim
e
t
0
140% of rated value in
p
u
t
Rated input
p
t
0
:
rated inte
g
ration tim
e
• Other items
Displayed value Output
140% Approx. 7.0 V
100% 5.0 V
0% 0 V
–100% –5.0 V
–140% Approx. –7.0 V
D/A output
Approx. 7.5 V
Approx. 7.0 V
5.0 V
0
–5.0 V
–100
100
–140
140
Approx. –7.0 V
Approx. –7.5 V
Displayed value [%]
• For PF and deg, points in the range from +5 to +7 V and from –5 to –7 V are not
output. If there is an error, the output will be about ±7.5 V.
• If the MATH setting is set to efficiency, the output will be +5 V for 100%
• For Vp and Ap, the output will be ±5 V when the value is three times (six times
if the crest factor is set to 6) the range.
9.3 D/A Output (Option)
