10-14
IM 760401-01E
Setting the Output Item in case of Harmonic Measurement
1.
SHIFT
SETUP
OUTPUT
ENTER
3.
( Display C )
( Display C )
2.
ENTER
5.
4.
Set the output item
( Display C )
ENTER
9.
End of setting
6.
6.
Sets the A column (output function)
7.
Moves to the B column
8.
Select from element 1 to 3
A
B
SHIFT
*
*
When graph printouts are selected as
the output item, only data values will be
output by communication
10.6 Setting the Output Items
173
