15-5
IM 760401-01E
Maintenance and Troubleshooting
15
9. Repeat steps 2 to 6 to adjust channel 2.
10. Repeat steps 2 to 6 for all channels to be adjusted.
11. Press The SHIFT key and display C will change to “dA”. This completes the D/A
output adjustments. When you press the RESET key instead of the SHIFT key,
the carried out adjustments will become invalid.
After Finishing Adjustments
After having finished all adjustments, turn the power OFF and ON again.
Communication Commands for Adjustment
Command Description
CAL1 Enters range adjustment mode.
CR0 Switches to 15 V range in range adjustment mode.
CR1 Switches to 30 V range in range adjustment mode.
CR2 Switches to 60 V range in range adjustment mode.
CR3 Switches to 150 V range in range adjustment mode.
CR4 Switches to 100 mA range in range adjustment mode (WT210only).
CR5 Switches to 500 mA range in range adjustment mode.
CR6 Switches to 1 A range in range adjustment mode.
CR7 Switches to 2 A range in range adjustment mode.
CR8 Switches to 5 A range in range adjustment mode.
CR11 Switches to 150 V range in range adjustment mode with the line filter turned ON.
CR12 Switches to 1 A range in range adjustment mode with the line filter turned ON.
CAN Exits range adjustment mode discarding the adjustments. Corresponds to the
RESET key.
END Exits range adjustment mode keeping the adjustments. Corresponds to the SHIFT
key.
ENT Confirms the adjustment value. Corresponds to the ENTER key.
CAL2 Enters external sensor input range adjustment mode.
EX0 No external sensor input option.
EX1 Option /EX1 (2.5 V, 5 V, and 10 V ranges)
EX2 Option /EX2 (50 mV, 100 mV, and 200 mV ranges)
CR9 /EX2 Switch to 200 mV range.
CR10 /EX1 Switch to 10 V range.
CAN Exits range adjustment mode discarding the adjustments. Corresponds to the
RESET key.
END Exits range adjustment mode keeping the adjustments. Corresponds to the SHIFT
key.
ENT Confirms the adjustment value. Corresponds to the ENTER key.
CAL3 Enter D/A output adjustment mode.
CHm Switches channels in D/A output adjustment mode.
m = 1 to 12
CDm,n Enter the actual output value in D/A output adjustment mode.
m = 1 to 12, n = actual output value.
DO0 Execute +5 V output in D/A output adjustment mode.
DO1 Execute –5 V output in D/A output adjustment mode.
CAN Exits range adjustment mode discarding the adjustments. Corresponds to the
RESET key.
END Exits range adjustment mode keeping the adjustments. Corresponds to the SHIFT
key.
ENT Confirms the adjustment value. Corresponds to the ENTER key.
CAL0 Exits adjustment (returns to normal measurement mode).
OD Communication output request for measured/computed data. The output format is
normally default.
Note
• In case of D/A adjustment, change the channel using the CHm command, then carry out DO0
or DO1 command, and the request output using the CDm,n command. After the CDm,n
command is being executed by +5 V or –5 V, make sure to confirm by the ENT command.
• After the display has been stabilized in the range adjustment mode or external sensor input
range adjustment mode, execute the ENT command.
15.1 Adjustments
