4-10 IM 760401-01E

On the WT210

• When the crest factor is set to 3

Voltage Current Range

Range (V) 500.00 mA 1.0000 A 2.0000 A 5.0000 A 10.000 A 20.000 A

15.000 7.5000 W 15.000 W 30.000 W 75.000 W 150.00 W 300.00 W

30.000 15.000 W 30.000 W 60.000 W 150.00 W 300.00 W 600.00 W

60.000 30.000 W 60.000 W 120.00 W 300.00 W 600.00 W 1.2000 kW

150.00 75.000 W 150.00 W 300.00 W 750.00 W 1.5000 kW 3.0000 kW

300.00 150.00 W 300.00 W 600.00 W 1.5000 kW 3.0000 kW 6.0000 kW

600.00 300.00 W 600.00 W 1.2000 kW 3.0000 kW 6.0000 kW 12.000 kW

Voltage Current Range

Range (V) 5.0000 mA 10.000 mA 20.000 mA 50.000 mA 100.00 mA 200.00 mA

15.000 75.000 mW 150.00 mW 300.00 mW 750.00 mW 1.5000 W 3.0000 W

30.000 150.00 mW 300.00 mW 600.00 mW 1.5000 W 3.0000 W 6.0000 W

60.000 300.00 mW 600.00 mW 1.2000 W 3.0000 W 6.0000 W 12.000 W

150.00 750.00 mW 1.5000 W 3.0000 W 7.5000 W 15.000 W 30.000 W

300.00 1.5000 W 3.0000 W 6.0000 W 15.000 W 30.000 W 60.000 W

600.00 3.0000 W 6.0000 W 12.000 W 30.000 W 60.000 W 120.00 W

• When the crest factor is set to 6

Voltage Current Range

Range (V) 250.00 mA 500.00 mA 1.0000 A 2.5000 A 5.0000 A 10.000 A

7.5000 1.8750 W 3.7500 W 7.5000 W 18.750 W 37.500 W 75.000 W

15.000 3.7500 W 7.5000 W 15.000 W 37.500 W 75.000 W 150.00 W

30.000 7.5000 W 15.000 W 30.000 W 75.000 W 150.00 W 300.00 W

75.000 18.750 W 37.500 W 75.000 W 187.50 W 375.00 W 750.00 W

150.00 37.500 W 75.000 W 150.00 W 375.00 W 750.00 W 1.5000 kW

300.00 75.000 W 150.00 W 300.00 W 750.00 W 1.5000 kW 3.0000 kW

Voltage Current Range

Range (V) 2.5000 mA 5.0000 mA 10.000 mA 25.000 mA 50.000 mA 100.00 mA

7.5000 18.750 mW 37.500 mW 75.000 mW 187.50 mW 375.00 mW 750.00 mW

15.000 37.500 mW 75.000 mW 150.00 mW 375.00 mW 750.00 mW 1.5000 W

30.000 75.000 mW 150.00 mW 300.00 mW 750.00 mW 1.5000 W 3.0000 W

75.000 187.50 mW 375.00 mW 750.00 mW 1.8750 W 3.7500 W 7.5000 W

150.00 375.00 mW 750.00 mW 1.5000 W 3.7500 W 7.5000 W 15.000 W

300.00 750.00 mW 1.5000 W 3.0000 W 7.5000 W 15.000 W 30.000 W

Note

WheThe maximum display is 99999 (when the number of displayed digits is set to 5).n the

range is set to auto, the measuring range switches according to range up/range down

conditions. Therefore, the range may vary even if the measured values remain the same.

4.4 Selecting the Measurement Range When Using Direct Input
