3. PART NAMES AND FUNCTIONS
3. PART NAMES AND FUNCTIONS
3.1 Part Names
F0301.EPS
F0301.EPS
Amp. cover
LCD assembly
(with indicator)
Burn out output direction
setting pin upon hardware failure
CPU assembly
Stud bolt
Name plate
Grounding
terminal
Terminal cover
Grounding
terminal
Wiring connector
(input signal side)
Output signal terminal
Wiring connector
(output signal side)
Input signal terminal
Tag plate
Lock screw
Built-in indicator display
Figure 3.1 Part Names
