YOKOGAWA YTA110 User Manual

IM 01C50B01-01E
7-6
7. STANDARD SPECIFICATIONS
[For Explosion Protected Types]
For FOUNDATION Fieldbus explosion protected type, see IM 01C50T02-01E.
CENELEC ATEX (KEMA) Intrinsically safe, Flameproof approval and Type n combination
[Intrinsically safe approval]
II 1G EEx ia IIC T4,T5 Ambient Temerature : -40 to 70°C for T4, -40 to 50°C for T5
Supply/Output circuit : Ui=30V, Ii=165mA, Pi=900mW, Ci=20nF, Li=660H
Input circuit : Uo=8.6V, Io=30mA, Po=70mW, Co=3F, Lo=20mH
Electrical Connection : 1/2 NPT female and M20 female*
1
[Flameproof approval]
II 2G EEx d IIC T5, T6 Ambient Temerature : -40 to 80C for T5, -40 to 75C for T6
Electrical Connection : 1/2 NPT female and M20 female*
1
[Type n approval]
II 3G EEx nL llC T4, T5 Ambient Temperature : -40 to 70C for T4, -40 to 50C for T5
Supply/Output circuit : Ui=30V, Ci=20nF, Li=660H
Input circuit : Uo=8.6V, Io=30mA, Po=70mW, Co=3F, Lo=20mH
Electrical Connection : 1/2 NPT female and M20 female*
1
CENELEC
Factory Mutual (FM)
Japanese Industrial
Standards (JIS)
Item
Descriptions
Code
KU2
FM Explosionproof approval
Explosionproof Class I, Division 1, Groups A, B, C and D;
Dust-ignitionproof for Class II/III, Division 1, Groups E, F and G.
“FACTORY SEALED, CONDUIT SEAL NOT REQUIRED.” Enclosure Rating: NEMA 4X
Temperature Class : T6 Ambient Temperature : -40 to 60C (-40 to 140F)
Electrical Connection : 1/2 NPT female*
2
FM Intrinsically safe, non-incendive and Explosionproof approval combination*
4
[Intrinsically safe/non-incendive approval]
Intrinsically safe for Class I, II, III Division 1 Groups A, B, C, D, E, F and G.
Non-incendive for Class I, II, Division 2 Groups A, B, C, D, E, F and G Class III, Division 1.
Enclosure Type : 4X Temperature Class : T4 Ambient Temperature : -40 to 60C (-40 to 140F)
Supply : Vmax=30V, Imax=165mA, Pmax=0.9W, Ci=18nF, Li=730H
Sensor : Voc=9V, Isc=40mA, Po=90Mw, Ca=1F, La=10mH
[Explosionproof approval]
Class I, Division 1, Groups A, B, C and D.;
Dust-ignitionproof for Class II/III, Division 1, Groups E, F and G.
"FACTORY SEALD, CONDUIT SEAL NOT REQUIRED." Enclosure Ratings : NEMA4X
Temperature Class : T6 Ambient Temperature : -40 to
60C (-40 to 140F)
Electrical Connection : 1/2NPT female*
2
JIS Flameproof approval
Ex ds IIC T6 X Amb. Temp. : -20 to 60
C
Attached flameproof
packing adapter*
3
Electrical connection : G1/2 female
Applicable cable : O.D. 8.5 to 11 mm
FF1
FU1
JF3
G111 pc.
G122 pc.
*1 : Applicable for Electrical Connection Code 2 and 4.
*2 : Applicable for Electrical Connection Code 2.
*3 : If cable wiring is to be used to a JIS flameproof type transmitter, do not fail to add the YOKOGAWA-assured flameproof packing
adapter.
*4 : Not applicable for Output Signal Code F.
*5 : Applicable for Electrical connection code 2, 3 and 4.
T0706.EPS
CENELEC (KEMA) Intrinsically safe, Type n and Flameproof approval combination
[Intrinsically safe approval]
EEx ia llC, T4, T5 Ambient Temperature : -40 to 70C for T4, -40 to 50C for T5
Supply/Output circuit : Ui=30V, Ii=165mA, Pi=0.9W, Ci=20nF, Li=660H
Input circuit : Uo=8.6V, Io=30mA, Po=0.07W, Co=3F, Lo=20mH
Electrical Connection : 1/2 NPT female, Pg13.5 female and M20 female*
5
[Type n approval (IEC) ]
Ex nC llC, T4/T5 Ambient Temperature : -40 to 70C for T4, -40 to 50C for T5
Supply/output circuit : Ui=30V, Ii=150mA
Input circuit : Uo=8.6V, Io=30mA, Po=70mW
Electrical connection : 1/2 NPT female, Pg13.5 female and M20 female*
5
[Flameproof approval]
EEx d llC T6, Ambient Temperature : -40 to 75C
Electrical Connection : 1/2 NPT female, Pg13.5 female and M20 female*
5
KU1
Standards
Association of
Australia (SAA)
SAA Intrinsically safe, non-sparking and Flameproof approval combination
Ex ia IIC T4 (Tamb=70
C) IP66/67, Ex n IIC T4(Tamb=70 C) , IP66/67
Input parameters : Ui=30V, Ii=165mA, Pi=0.9W
Output parameters : Uo=8.6V, Io=30mA, Po=62mW, Co=1F
Ex d IIC T6 (Tamb=75
C) IP66/67
Electrical connection : 1/2 NPT female, Pg13.5 female and M20 female*
5
SU1
