The Other YN-622C User Guide v.4.09
11/12/2014 Part 1 – The System Page 17 of 64
Type C Camera – Sync only
• Does not support HSS or E-TTL functions.
• Max speed sync is 1/250s or less.
622C Transmitter and C-TX Controller using all flash classes: A “fire!” synchronised signal
• A camera with a standard single-pin hot-shoe.
• A camera with a PC-sync-out connection.
• A non-Canon ISO multi-pin hotshoe with an adapter to allow only the centre (X-sync) pin to
be accessible (e.g. Nikon).
• A brand-specific hot-shoe with an adapter to Canon hotshoe (e.g. Sony/Minolta).
FLASH COMPATIBILITY
Flashes can be grouped into five classes.
• The 622C is rated at only 6 volts on the trigger contact of its hot-shoe. The PC-sync
connection can withstand 300 volts.
Class 1 Flash – Remote E-TTL; Remote Manual Levels
622C: Set using External Flash menus not the on-Flash buttons.
C-TX: Set on C-TX, or by External Flash menus. On-flash settings are available for special lighting.
Brand HSS No HSS
Canon 580EX II, 600EX-RT
No Multi: 270EX II, 430EX II
Godox Ving V860C
Jessop No Multi: 360AFDC
Metz No Multi: 50 AF-1, 58 AF-2
Neewer NW680
Nissin Di866 II
Phottix Mitros
Yongnuo YN-500EX, YN-568EX YN-465, YN-467 II, YN-468 II, YN-565,
YN-565 II (YN-467, YN468 ?)
Class 2 Flash – Remote E-TTL; Flash-set Manual Levels
622C Set On-Camera: Sync mode (1CS, 2CS, HSS); ETTL (FEC, FEB, FEL and Ratio).
Set on-flash: Flash mode (ETTL, M, Multi); Zoom; Manual levels.
C-TX Set on C-TX: or by External Flash menus For remote Manual levels on Canons, set C.Fn 05
to “On”, and set the mode on Flash to “E-TTL”.
Brand HSS No HSS
Canon 550EX, 580EX. No Multi: 430EX
Metz No Multi: 48 AF-1, 48 AF-2,
54mz4 (Mix mode, Wireless disabled)
Nissin Di866 Di622 II
Pixel Mago
Sigma No Multi: EF 500, 530, 610 DG Super
Sunpak No Multi: Z42X
