YooFab RFLEGO - Step-by-Step Component Installation

To Next Page

To Previous Page

Step By Step

We are going to build this kit, using a step by step method, which irrespective of

your skill, you are strongly advised to follow.

We will start by soldering components on the copper side of the board. However, when

completed, the module's front panel is the non copper side of the board.

Where possible, an illustration and a photograph are shown. The photographs show a

prototype board with the same design.

In most cases, the photographs in the instructions below show soldering by a

novice at the YooFab Lab. Despite this, the modules worked perfectly first time.

ASSEMBLY INSTRUCTIONS

RFLEGO Active Antenna Receiving Loop
