1. All RFLEGO modules are compatible with each other and make use of standard
Banana connectors for power (except where specified), while signal lines use
RCA connectors.
2. YooFab RCA 50Ω patch leads may be used directly to connect RFLEGO
modules together.
3. Adapters are available to convert RCA to BNC, SMA or PL-259 SO-239.
4. High quality components are sourced from trusted suppliers. All components are
mounted on a single sided, predrilled printed circuit board. The board is
supplied with a vinyl protection, no legend, solder resist or other markings.
5. The PCB style used is popular among RF design engineers.
6. RFLEGO is a term used to convey the modular and connective nature of an
educational and functional system that is the intellectual property of YooFab™.
7. The PCBs are hand crafted at the YooFab™ workshop.
