Name Value Quantity Notes
C1, C2, C3, C4, C5, C6,
C7
100nF 7 disk ceramic capacitor
C8 100uF 1 electrolytic capacitor more than 25 V
D1 led 1 red
FT37-43 10T BIFILAR 1 https://www.micrometals.com
Q1, Q2 2N2222 2 Transistor NPN
R1, R2 120Ω 2 Resistor
R3, R4, R9 1K 3 Resistor
R5, R8 4.7K 2 Resistor
R6, R7 270Ω 2 Resistor
Printed Circuit Board 1 Vinyl protected copper
35 mm stand-off 4 Black plastic
M3 bolt 4 Black plastic
washer 5 mm 2 Led finishing
RCA connector (Phono) 1 Gold Plated
Banana Connector 2
Power Connector 2.1 mm 1
Wire red and black 2
Galvanized wire 1 m length
Decal 1 To be placed on top of the PCB
Polystyrene piece 1 To organize your components while building
ASSEMBLY INSTRUCTIONS
RFLEGO Active Antenna Receiving Loop
Copyright © 2018 - 2019 www.yoofab.com G.D.COWNE - MØOOZ page 7 of 66
