Figure 7: 0105 component locations
Figure 8: 0140 component locations
Callout Description Callout Description
1 Unit one G Hot water heat-exchanger
2 Unit two H Control circuits transformer
A Fans I Ventilation fan
B Control panel J Pressure relief
C Accumulator K HMI
D Compressor L Chilled water heat-exchanger
E Receiver M SPC box
F Ambient coil – –
YMAE Air-Cooled Inverter Scroll Chiller and Heat Pump28
