Figure 17: Internal hydronic kit, two pipe single module
Callout Description Callout Description
A Internal hydronic kit C Protective plate
B Two-pipe single module – –
Note: You must remove the protective plate before commissioning.
33YMAE Air-Cooled Inverter Scroll Chiller and Heat Pump
