Page – 76/155 AF6ZP0CA – COMBIAC0 & ACE0 2uC – User Manual
HARDWARE SETTING
Parameter Allowable range Description
FEEDBACK SENSOR
(A)
0 ÷ 6 This parameter defines the type of the adopted speed
sensor. Factory adjusted.
0 = Incremental encoder.
1 = Sin/cos sensor.
2 = Incremental encoder + sin/cos sensor.
3 = Incremental encoder + sin/cos sensor + index.
4 = PWM absolute sensor + incremental encoder +
index.
5 = Resolver.
6 = Hall effect sensor (six-step).
POSITIVE E.B.
(A)
0 ÷ 2 This parameter defines the hardware configuration for the
positive terminal of the electromechanical brake PEB (A2).
0 = PEB is managed by the smart driver (available for
24V version only).
1 = PEB comes from the TILLER input (A1). The internal
jumper must be properly configured.
2 = PEB comes from PEV (A3). PEV must be connected
to terminal +B of the controller. This is the default
configuration for 36/48V and 80V version.
ROTATION CW ENC
(A)
OPTION#1 ÷ OPTION#2 It defines how the signal sequence coming from the
encoder channels is expected by controller
OPTION#1 = Channel A anticipates channel B.
OPTION#2 = Channel B anticipates channel A.
ROTATION CW MOT
(A)
OPTION#1 ÷ OPTION#2 It permits to change the sequence in which the motor
phases are powered. Factory adjusted.
OPTION#1 = U-V-W corresponds to forward direction.
OPTION#2 = V-U-W corresponds to forward direction.
ROTATION CW POS
(Only for BLE0)
(A)
OPTION#1 ÷ OPTION#2 It permits to reverse the direction read by the absolute
position sensor.
OPTION#1 = Sin anticipates cos.
OPTION#2 = Cos anticipates sin.
ENCODER PULSES 1
(A)
32 ÷ 1024 This parameter defines the number of encoder pulses per
revolution. It must be set equal to ENCODER PULSES 2;
otherwise the controller raises an alarm.
The available options are:
32, 48, 64, 80, 64, 128, 256, 512, 1024
NOTE: with standard HW, the capability to use encoders
with high number of pulses could be limited depending on
the speed. Ask to Zapi technician before to operate on this
parameter
To Next Page
