Zapi ACE0 2mC - Program Vacc; Lift & Lower Command Acquiring

AF6ZP0CA – COMBIAC0 & ACE0 2uC – User Manual Page – 143/155
13.1.4 Program Vacc
Choose “Function” > “Program VACC” menu.
When “Acquire” is pressed, the PROGRAM VACC procedure will start:
 Select the Enable switch, if any;
 Select the direction switch (either forward or backward);
 Press the pedal up to its maximum excursion.
Displayed values will vary accordingly to operator inputs.
13.1.5 Lift & Lower command acquiring
Once you are connected to the inverter, you need to download the parameters;
choose “Function” > “Parameter” menu (or push the “Parameter” icon).
Choose “Adjustment” menu.
Select the value you want to acquire by pressing the “acquiring” button and the
acquisition will start:
