AF6ZP0CA – COMBIAC0 & ACE0 2uC – User Manual Page – 67/155
SET OPTIONS
Parameter Allowable range Description
DISPLAY TYPE
(T, TM, P)
0 ÷ 9 This parameter defines which type of display is connected
to the inverter.
0 = None.
1 = MDI PRC.
2 = ECO DISPLAY.
3 = SMART DISPLAY.
4 = MDI CAN.
5 ÷ 9 = available for future developments.
ABS.SENS.ACQUIRE
(Only for BLE0 with
sin/cos or PWM sens)
(A)
OFF ÷ ON This parameter activates the acquisition of motor speed
sensor used for PMSM (Permanent-Magnets Synchronous
Motor).
Contact Zapi technicians for a detailed description of
the acquisition procedure.
4 IMPORTANT NOTE: output EV5 may be not available depending on hardware
configuration even if the parameter EV5 is set as PRESENT.
8.2.3 ADJUSTMENTS
ADJUSTMENTS
Parameter Allowable range Description
SET BATTERY
(A)
24 V ÷ 80 V This parameter must be set to the nominal battery voltage.
The available options are:
24V, 36V, 48V, 72V, 80V
ADJUST KEY VOLT.
(A)
Fine adjustment of the key voltage measured by the
controller. Calibrated by Zapi production department during
the end of line test.
ADJUST BATTERY
(A)
Fine adjustment of the battery voltage measured by the
controller. Calibrated by Zapi production department during
the end of line test.
SET POSITIVE PEB
(A)
12 V ÷ 80 V This parameter defines the supply-voltage feeding pin A3.
The available values are:
12V, 24V, 36V, 40V, 48V, 72V, 80V
SET PBRK. MIN
(T, TM, CO)
0 V ÷ 25.5 V
(steps of 0.1V)
It records the minimum value of brake potentiometer when
the brake is analog.
SET PBRK. MAX
(T, TM, CO)
0 V ÷ 25.5 V
(steps of 0.1V)
It records the maximum value of brake potentiometer when
the brake is analog.
