Page – 72/155 AF6ZP0CA – COMBIAC0 & ACE0 2uC – User Manual
8.2.4 SPECIAL ADJUST.
4 Note: SPECIAL ADJUST. must only be accessed by skilled people. To change
settings in this group of settings, a special procedure is needed. Ask for this
procedure directly to a Zapi technician. In SPECIAL ADJUST. there are
factory-adjusted parameters that should be changed by expert technicians only.
SPECIAL ADJUST.
Parameter Allowable range Description
ADJUSTMENT #01
(Read Only)
(A)
Gain of the first traction-motor current-sensing amplifier.
NOTE: only Zapi technicians can change this value through
a special procedure.
ADJUSTMENT #02
(Read Only)
(A)
Gain of the second traction-motor current-sensing amplifier.
NOTE: only Zapi technicians can change this value through
a special procedure.
CURR. SENS. COMP
(A)
OFF ÷ ON This parameter enables or disables the linear compensation
for the current sensors.
NOTE: only Zapi technicians can change this value through
a special procedure.
DIS.CUR.FALLBACK
(A)
OFF ÷ ON This parameter disables or enables current reduction
(applied after one minute of traction).
ON = Current reduction is disabled.
OFF = Current reduction is enabled.
SET CURRENT
(Read Only)
(A)
See table on the right (Factory adjusted). This is maximum current that the
inverter can provide to the motor.
Controller
voltage
Allowable values
[Arms]
24V 220, 320, 350
36V/48V 180, 280, 320
80V 200
SET TEMPERATURE
(A)
0°C ÷ 255°C
(steps of 1°C)
This parameter calibrates the controller-temperature
reading.
HW BATTERY RANGE
(Read Only)
(A)
0 ÷ 3
(steps of 1)
This parameter defines the battery voltage range.
NOTE: only Zapi technicians can change this value.
DUTY PWM CTRAP
(Read Only)
(A)
0% ÷ 100% This parameter defines the duty cycle for overcurrent
threshold. Reserved.
