AF6ZP0CA – COMBIAC0 & ACE0 2uC – User Manual Page – 131/155
10.4 Alarms from supervisor µC
Error
Code
Effect Condition
Restart
procedure
MDI /
LED
CODE
CAN
OPEN
CODE
ZAPI
CODE
BUMPER STOP
Traction sopped
Start-up, stand-by,
running
0 FFC7 199
WATCHDOG
MC is opened, EB is applied,
traction/pump stopped
Stand-by, running Key re-cycle 8 6010 8
CONTROLLER MISM.
MC is not closed, EB is applied,
Traction/Pump, valves stopped
Start-up
Install the correct
software and Key
re-cycle
12 FFEF 239
EEPROM KO
Controller works using default
parameters
Start-up, stand-by,
running
13 3610 208
PARAM RESTORE
No effect Start-up
Traction/Pump
request
14 3611 209
SP MISMATCH xx
MC is opened, EB is applied,
traction/pump stopped
Running Key re-cycle 15 FFF2 242
OUT MISMATCH xx
MC is opened, EB is applied,
traction/pump stopped
Running Key re-cycle 16 FFE3 227
LOGIC FAILURE #3
MC is opened, EB is applied,
traction/pump stopped
Stand-by
Valves or
Traction/Pump
request
17 FF11 17
SP MISMATCH PUMP
MC is opened, EB is applied,
traction/pump stopped
Running Key re-cycle 18 FFF1 241
OUT MISMATCH PU
MC is opened, EB is applied,
traction/pump stopped
Running Key re-cycle 20 FFF0 240
LOGIC FAILURE #1
MC is opened, EB is applied,
traction/pump stopped
Stand-by, running
Valves or
Traction/Pump
request
19 5114 19
INPUT MISMATCH
MC is opened, EB is applied,
Traction/Pump stopped
Start-up, standby,
running
Key re-cycle 58 FFD5 213
W.SET. TG-EB XX Traction/Pump motor is stopped
Start-up, stand-by,
running
Key re-cycle 59 FFD4 212
NO CAN MSG.
MC is opened, EB is applied,
Traction/Pump, valves stopped
Start-up, stand-by,
running
Valves or
Traction/Pump
request
67 8130 248
NO CAN WR MSG.XX No effect
Start-up, stand-by,
running
67 8131 229
WRONG RAM MEM.
MC is opened, EB is applied,
Traction/Pump, valves stopped
Stand-by Key re-cycle 71 FFD2 210
VDC LINK OVERV.
MC is not closed, EB is applied,
Traction/Pump, valves stopped
Stand-by, running
Valves or
Traction/Pump
request
77 FFCA 202
WRONG ENC SET
MC is not closed, EB is applied,
Traction/Pump, valves stopped
Start-up Key re-cycle 85 FF51 201
STEER SENSOR KO
EB is applied, traction/pump
stopped
Start-up, stand-by,
running
Key re-cycle 95 FFC3 200
ANALOG INPUT
MC is opened, EB is applied,
traction/pump stopped
Stand-by, running Key re-cycle 96 FFFA 237
10.4.1 Troubleshooting of alarms from supervisor µC
ANALOG INPUT (MDI/LED code = 96)
Cause:
This alarm occurs when the A/D conversion of the analog inputs returns
frozen values, on all the converted signals, for more than 400 ms. The goal of
this diagnosis is to detect a failure in the A/D converter or a problem in the
code flow that skips the refresh of the analog signal conversion.
Troubleshooting
If the problem occurs permanently it is necessary to replace the logic board.
