Zebra 105SL Plus User Manual

Printer Configuration and Adjustment
Calibrate the Ribbon and Media Sensors Manually
108
P1056468-002 7/3/13
4. What type of media are you using? For more information, see Types of Media on page 47.
If you are using… Then…
Media where labels are
separated by gaps
a. Set the sensor type to WEB. (See Sensor Type on page 102.)
b. Extend approximately 8in. (203 mm) of media out of the printer.
c. Remove and discard the labels from this exposed media.
d. Pull the backing into the printer.

Zebra 105SL Plus Specifications

General

Weight	50 lbs / 22.7 kg
Humidity	20-85% non-condensing
Print Method	Thermal Transfer
Resolution	203 dpi (8 dots/mm)
Max Print Width	4.09 inches / 104 mm
Max Print Speed	12 inches per second / 305 mm per second
Memory	16 MB SDRAM, 8 MB Flash
Media Width	0.79 inches / 20 mm to 4.5 inches / 114 mm
Media Thickness	0.003 inches / 0.076 mm to 0.012 inches / 0.305 mm
Media Types	Continuous, die-cut, black mark
Ribbon Width	2.00 inches / 51 mm to 4.33 inches / 110 mm
Ribbon Length	1476'/450 m
Connectivity	Parallel, Serial
Optional Connectivity	Ethernet, Wireless
Power Requirements	90-264 VAC; 48-62 Hz
Operating Temperature	40°F to 105°F / 5°C to 40°C
Storage Temperature	-40°F to 140°F / -40°C to 60°C
