Zebra 105SL Plus User Manual

131
Routine Maintenance
Cleaning Schedule and Procedures
7/3/13 P1056468-002
3. Insert a small-blade screwdriver or similar tool into the loop on the left side of the snap
plate. Gently lift the left side of the snap plate slightly and, if necessary, support it with
your left hand.
4. Insert the small-blade screwdriver or similar tool into the loop on the right side of the snap
plate. Gently lift the right side of the snap plate.
Important • Take care not to bend, twist, or otherwise deform the loops. If the snap plate
is damaged in any way, you may need a new plate for proper ribbon sensing.

Zebra 105SL Plus Specifications

General

Weight	50 lbs / 22.7 kg
Humidity	20-85% non-condensing
Print Method	Thermal Transfer
Resolution	203 dpi (8 dots/mm)
Max Print Width	4.09 inches / 104 mm
Max Print Speed	12 inches per second / 305 mm per second
Memory	16 MB SDRAM, 8 MB Flash
Media Width	0.79 inches / 20 mm to 4.5 inches / 114 mm
Media Thickness	0.003 inches / 0.076 mm to 0.012 inches / 0.305 mm
Media Types	Continuous, die-cut, black mark
Ribbon Width	2.00 inches / 51 mm to 4.33 inches / 110 mm
Ribbon Length	1476'/450 m
Connectivity	Parallel, Serial
Optional Connectivity	Ethernet, Wireless
Power Requirements	90-264 VAC; 48-62 Hz
Operating Temperature	40°F to 105°F / 5°C to 40°C
Storage Temperature	-40°F to 140°F / -40°C to 60°C
