Zebra 105SL Plus User Manual

45
Printer Setup and Operation
Connect the Printer to a Power Source
7/3/13 P1056468-002
Figure 5 • Power Cord Specifications
Figure 6 • International Safety Organization Certification Symbols
1
AC power plug for your country—This should bear the certification
mark of at least one of the known international safety organizations
(Figure 6).
2
3-conductor HAR cable or other cable approved for your country.
3
IEC 320 connector—This should bear the certification mark of at
least one of the known international safety organizations (Figure 6).
4
Length ≤ 9.8 ft. (3 m). Rating 10 Amp minimum, 250 VAC.
3
1
2
4

Zebra 105SL Plus Specifications

General

Weight	50 lbs / 22.7 kg
Humidity	20-85% non-condensing
Print Method	Thermal Transfer
Resolution	203 dpi (8 dots/mm)
Max Print Width	4.09 inches / 104 mm
Max Print Speed	12 inches per second / 305 mm per second
Memory	16 MB SDRAM, 8 MB Flash
Media Width	0.79 inches / 20 mm to 4.5 inches / 114 mm
Media Thickness	0.003 inches / 0.076 mm to 0.012 inches / 0.305 mm
Media Types	Continuous, die-cut, black mark
Ribbon Width	2.00 inches / 51 mm to 4.33 inches / 110 mm
Ribbon Length	1476'/450 m
Connectivity	Parallel, Serial
Optional Connectivity	Ethernet, Wireless
Power Requirements	90-264 VAC; 48-62 Hz
Operating Temperature	40°F to 105°F / 5°C to 40°C
Storage Temperature	-40°F to 140°F / -40°C to 60°C
